Serial number

Project

Parameter

1

Engine model

KTA50-G3

2

Generator model

TZHW3-1000KW

3

Set manufacturer

MingFa power generation equipment Co., Ltd.

4

Technical specifications

5

Rated power of the crew

1000KW

6

Voltage

400V-220V

7

Rated power

50HZ

8

Power factor

0.8 lagging

9

Phase number/Number of lines

Three phase four wire

10

Speed regulation type

Electronic speed regulation

11

Neutral grounding mode

Direct grounding

12

Installation method of crew

Fixed type

13

Size（long×wide×high）

5300×1500×2640

14

Weight

10800㎏

15

Engine

16

Manufactor

ChongQing Cummins Engine Co., Ltd.

17

Model

KTA50-G3

18

Cylinder number and Type

12 cylinder V type

19

Speed

1500 turn/minute

20

Cylinder diameter×Trip

159×159㎜

21

Engine maximum power

1227KW

22

Cooling mode

Cooling water tank with fan

23

Starting battery

200A×4

24

Electric starting system

24 volt DC starting motor

25

Fuel consumption rate  g（kw.h）

≤258

26

Lubricating oil capacity

50L

27

Fuel

Diesel oil

28

Alternator

29

Manufactor

Lanzhou Electric Motor Co., Ltd.

30

Model

TZHW3-1000KW

31

Insulation grade

F

32

Excitation mode

Brushless self excited 4 pole

33

Rated voltage

400V

34

Voltage control mode

Automatic voltage regulator AVR

35

Voltage adjustment rate

±10%

36

Generator steady voltage adjustment

±1%

37

Protection grade

IP:21

38

Control system

Self starting device
