Features:Raise the frequency from 50/60Hz to high frequency. E. G. 100kHz. After reducing the voltage and rectifying, output powerful Dcwith the technology of PWM. The weight and size of the main transformer decrease dramatically but the efficiency will rise by over 30%
1. With the function of auto-compensation against power fluctuation. And the ouput welding current will be stable.
2. Having the function of auto-protection against over-voltage and over-current;
3. Having powerful arc-force;
4. Reliable quality with small dimension and weight as well as high efficieny;
5. Able to weld basic and acid electrodes;
6. Applicable to low carbon steel, medium carton steel and alloy steel.
Details:| Parameter/Model | ARC300(MOS) |
| Input Voltage | AC380V±15% |
| Frequency | 50/60 |
| Rated Input Current | 21 |
| No-load Voltage | 60 |
| Output Current Range | 30-300 |
| Rated Output Voltage | 32 |
| Duty Cycle | 60 |
| No-load Loss | 80 |
| Efficiency | 85 |
| Power Factor | 0.93 |
| Insulation Grade | F |
| Housing Protection Grade | IP21 |
| Net Weight | 17.5 |
| Dimension | 480*204*303 |
| Accessories | Earth clamp with 3M cable(25mm2 500A)
Electrode holder with 3M cable (25mm2 500A) |
