| pecification | |
| Rated Load | 3000 kg |
| Operating Weight | 9280 kg |
| Bucket Capacity | 1.7m³ |
| Log Fork Width | |
| Bucket Width | 2400mm |
| Dimensions L*W*H(mm) | 7350x2235x3710 mm |
| Engine | |
| Model | WEICHAI DEUTZ |
| Rated Power | 92kW |
| Max. Torque | 500Nm |
| Operating Specifications | |
| Max.Drawbar Pull | 92kN |
| Max. Breakout Force | 130kN |
| Hydraulic System Pressure | 16 MPa |
| Hydraulic Cycle Times | 10.2 s |
| Steering System | |
| Steering Angle Left/Right | 36º±1º |
| Minimum Turing Radius (Over Rear Tire) | 5029 mm |
| Minimum Turing Radius (Over Bucket ) | 5500 mm |
| Transmission | |
| Type | YJ320B/BEILIAN280 |
| Speed Gears | F4/R2 |
| Axle | |
| Brand | Meritor/Hualu |
| Front Axle | Fixed with calipers |
| Rear Axle | Fixed with Osc.frame and calipers |
| Brake System | |
| Service Brake | Single circuit,oil brake |
| Parking Brake | hand operated |
| Tires | |
| Size | 17.5-25 |
| Type | Wave pattern |
