Hot Selling Coal Gasification Equipment/Coal Gasifier /Coal Gas Equipment (China Factory price)

Hot Selling Coal Gasification Equipment/Coal Gasifier /Coal Gas Equipment(China Factory price)

Coal gasifier Characteristics:

Special pagoda-type grate ventilation system, with more uniform air distribution, more uniform and thorough combustion, direct combination of vapor acting as gas agent with air, vapor used more completely and classification rate improved more efficiently to over 90%

Special ash pan, furnace wall always protected by slags, slag loosing and ventilation, disposing fundamentally the concept that gas furnace is the same as pressure vessel, heating temperature auto-controlled.

Widely used in the environment-friendly and energy-saving technological renovation of gas-processing heating furnace, gas forging furnace, gas crucible furnace, gas mold furnace, grilled ladle gas furnace, sand resin heating gas regenerater, glass melting gas furnace, ceramic gas furnace, as well as smoke exhausting refractory kiln and tunnel kiln.

Gasifier remove slags:

QM-2 wet-type slag removing coal classifier series if placed on ground level, ashes can be disposed conveniently, and humane operation.

Continual and cyclical manufacturing 24 hours a day of continuous work, without stopping to remove slags .

Easy to operate:

coal adding time by the temperature degree indication at the gas exit, This coal gasifier easy operation, needless of too much operation experience.

Long service time:

a unique pagoda-style heat-resistant cast iron furnace grate with once-and-for-all air distribution at the same time cooling the grate, the temperature of which maintained at between 150 and 25°C and the service time of the grate largely extended

Maintenance easy:

All the components of the furnace body are weld parts, so only need one welder is enough to complete furnace maintenance on the spot and the repairing time is short .

Have a hole is reserved in advance from which the repairman can enter conveniently, all the repair work can be done inside without dismantling the body and 8 hours is enough to finish the all maintenance tasks which will not affect the peak production.

Safer to use:

Safety is the lifeline of the enterprise, so the safety of the equipment chosen has been paid closest attention at all the slag removing places of QM-2 coal gasifier extensive waterseal explosion preventing grooves are set pervasively at the time of pressure rising, the pressure can be released in time and the explosion protection is delicate and effective.This is the first safety control

The second safety control is dedicated gas releasing and exhausting equipment, which should be opened when the furnace stops in order to exhaust the gas gathered in the main pipe and prevent the gas from being sucked back into the bore to explode when meeting fire.

Uniform combustion:

it has strong ability to break slags, which drop evenly along the circle of the slag pan, coal layers move downwards and does not lead to uneven coal burning as a result of the uneven seam density of coal

Uniform coal distribution:

at the coal adding place spacing devices were installed to prevent the cone valve from deviating resulting in uneven coal burning.
